Section 1. Unpacking and Installation
UNPACKING
Before unpacking your Doran scale, please read the instructions in this
section. Your new scale is a durable industrial product, but it is also a
sensitive weighing instrument. Normal care should be taken when
handling and using this product. Improper handling or abuse can damage
the scale and result in costly repairs that may not be covered by the
warranty. If you notice any shipping damage, notify the shipper
immediately. Please observe the following precautions to insure years of
trouble free service from your new scale.
! DO NOT drop the scale indicator or scale platform.
! DO NOT immerse the scale indicator or platform.
! DO NOT drop objects on the platform.
! DO NOT pick up the scale platform by the "spider. "
Carefully remove the scale from the shipping carton. Be sure to retain all
shipping materials in case the scale must be shipped elsewhere.
INSTALLATION:
Locate the desired position for the scale indicator. If the indicator is to be
permanently mounted to a wall, shelf, or counter, remove the mounting
bracket from the indicator. Use the two holes provided in the bracket to
affix it to the desired surface. Before mounting the indicator into the
bracket, connect the scale platform and any data cables to the indicator.
Insert one of the threaded case studs into one of the mounting holes on
the bracket. Now gently spread the sides of the bracket apart and insert
the other case stud into the hole on the opposite side. Loosely thread the
two knobs back onto the studs. Adjust the indicator to the desired viewing
angle and tighten down the knobs.
ELECTRICAL CONNECTIONS:
Your Doran scale requires 115 Vac, 50/60 Hz power (230 Vac 50/60Hz.
power optional). Be sure the AC power is not excessively noisy - this can
occur if large inductive loads, such as solenoids or motors, are on the
same power line. The Model 7000 and Model 7000XL have filtered power
supplies to reduce the effects of normal line noise, but they cannot limit
severe fluctuations. If problems occur, noise producing devices may have
to be suppressed to minimize their effect.
7
