Calibration Menu
CAL Zero Calibration Mode.
0 Calibration Zero
Press ZERO to perform calibration of the scale zero.
The raw counts should lie between -19,000 counts
and -10,000 counts.
CAL Span Calibration Mode.
(Does not appear if CAL 0 is not activated.)
FS Full load calibration.
Span should be greater than 21,000 raw counts
hS Half load calibration.
Span should be greater than 10,500 raw counts
4S Quarter load calibration.
Span should be greater than 5,300 raw counts
.1S 1/10
th
load calibration.
Span should be greater than 2,100 raw counts
NOTE: If the "span" or "zero" requirements are not met during
calibration, the scale will display "rg Er." If this occurs,
refer to section 5 and repeat the zero and span calibration.
NOTE: For maximum accuracy, Doran Scales recommends that all
scales be calibrated at full capacity. When location or
installation make it difficult to bring full capacity weights to
the scale, calibration with as little 10% of capacity is
possible.
17
