"F1" format: The "F1 format provides data compatibility with older Doran
Model 7000 Scales. The data representations use single characters for
scale status. This mode is intended for use in applications where a
computer is looking for the specific data format produced by the previous
versions of the Model 7000. The older 7000 format is no longer Legal for
Trade.
"SSP" format: The data string produced by the SSP format allows the
7000XL to communicate with the Doran Model SSP Label Printer. This
printer allows for the creation of custom labels containing weight
information, bar codes and graphics. Contact to your Authorized Doran
Scales Dealer for more information.
Fig 5. Sample SSP Format printer output.
"DGH" format: The DGH format allows the Model 7000 to communicate
with the Option Type "R" 4 to 20 mA analog output module. Selection of
this mode without the Type "R" option installed will result in an "Er Ao"
error.
35
FR"L1"
?
0.0
lb
GS
0.0
kg
P1,1
MOT.
Printer formatting strings.
Current weight data.
Current weight units.
Gross weigh status (always prints).
Motion status (when in motion).
Kilogram weight data.
Kilogram units
Printer formatting string.
(NOTE: Each line is terminated
with a line feed.)
