Fig. 3. Scale type selection jumper.
(Shown in 7000XL position.)
Table 4 Scale type selection jumpers.
Jumper Model 7000 Model 7000XL
JU20
IN OUT
JU21
LEFT TWO PINS RIGHT TWO PINS
JU22
LEFT TWO PINS RIGHT TWO PINS
