2) Once the correct capacity and filter have been selected, press and
release UNITS or S2 until the scale is in the raw counts mode. If the
capacity menu appears, scroll through the menu and try
again.
3) Remove any unneeded items from the platform.
4) Check the raw "zero" point. The raw "zero" should be between -19,000
counts and -10,000 counts. If not, adjust R10 until the raw counts lie
within this range. If the zero does not fall within this range, refer to
Section 5 for details on adjusting the zero and span range.
5) Check the raw "span." Place "Full Load" on the platform and verify that
the raw counts change by at least 21,000 counts. "Half Capacity" and
"Quarter Capacity" can be used in place of "Full Load". Use 10,500
counts and 5,250 counts change respectively.
If the span is not sufficient, refer to Section 5 for details on adjusting the
zero and span range.
13
