4
E7900 Series
2.1 Parts and Tools List
Each lockset includes:
(A) Outside lever handle
(or)
Parts for mechanical override model only:
(A1) Outside lever handle
(A2) Cylinder plug
(A3) Cylinder (locks with key cylinder)
(A4) Cylinder cap (locks with key cylinder)
(B) Outside housing
(C2) Torx-head screw (E900) (see hardware
bag)
(D) Mortise (ASM only shipped assembled with faceplate
and 2 x 8-32 x 1/4" screws)
(or)
Parts for cylindrical models (see illustrations in
appendix B):
cylindrical latch (see B2 page 46)
cylindrical unit assembled with one pair of screws &
3 spacers
four (4) other pairs of screws & 3 spacers in
hardware bag
additional extension spring
storeroom function locking screw and nut
(E3) Inside trim E-7900(N)
Parts inside hardware bag:
(F) Spindle E7900
(G) Square spindle
(C2) Torx-head screw (E7900)
(I) 3 x mounting screws (10-24, 1/8 Hex Head) or (12-24,
1/8" Hex Head for recent models only)
(J) 2 Machined screws (12-24X 1/2" Philips) & 2 wood
screws (#12 X 1" Philips)
(K) Strike kit (screws, strike and ASM or Cylindrical
dustbox)
(L) 1 extension spring
(M) Parts required to control thumbturn motion (ASM
and ASM Office) See appendix A2 & A3
(Q1) 4 pairs of Flat Head Screws 10-24 (for cylindrical only)
(R1) 3 Spacers (for cylindrical only)
(S) 3 spacers (see page 31) for recent Models only
(V) 2 x battery cover screws (4-40, 1/2 Torx Head)
(W) 1 Torx key (T10)
Tools Required:
• Safety glasses
• 1/2" (13mm) chisel
• 1/8" (3mm) drill bit
• 1/2" (13mm) drill bit
• 3/4" (19mm) drill bit
• 1" drill bit or hole saw
• 3/32" drill bit (Cylindrical only)
• 1/8" Hexagonal key (Allen key)
• Drill
• Awl or center punch
• 2 1/8" (54mm) hole saw (Cylindrical Only)
• Hammer Rubber mallet
• Small flat screwdriver
• Torx screwdriver (T-15)
• Phillips screwdriver (#2)
• Fine steel file
• Mortising machine
• Router
•
•
•
•
•
•
Mortise faceplate router template
Adjustable square
Tape measure
Pencil
Tape
Cleaning supplies (drop cloth, vacuum)
IMPORTANT
For doors more than 2 1/2" thick upto 3 3/4", order the
ap-propriate hardware bag to receive the correct
length of spindles and mounting screws. Part#
062-510189-XXX; (XXX = choice of finish).
For E7900 series, Gasket 033-512017-1 comes standard
for outdoor installations.
2 Checklist and Exploded Views
KD10114-E-1122
