Dormakaba ED900 - Parameters; ED900 - Viewing and Changing Parameters; Configuration Parameters; Driving Parameters

16
ED900 09-2021DL4617-001
dormakaba ED900 Setup and Troubleshooting Instructions Chapter 9
Step 
Press right button greater than  s to
enter program mode.
Step 
Press up or down button to scroll through
parameters until desired parameter is
displayed.
Step 
Press right button to display current
parameter value.
Step 
Press right button again to enable
editing of value, display will start
flashing.
Step 
Press up or down button to select
desired parameter value.
Step 
Press right button to save selected
value. Display stops flashing.
Step 
Press left button to return to selected
parameter.
Step 
Press up or down button to scroll
through parameters until next desired
parameter is displayed.
Step 
Press left button for a minimum of  s
to exit program mode.
.. Driving parameters.
Driving parameters (Table ..) can be set once initial
setup (Chapter ) has been completed.
• Reference Appendix A for driving parameter detail.
.. Changing parameter values.
. Set Mode switch to the CLOSE position.
Fig. 9.1.1 Mode switch
Fig. 9.1.2 4 button keypad, 2 digit display
2 2 digit display
5 4 button keypad
 Parameters
> 3s Reset
< 3s Quit
> 3s
PRG
< 3s
LEARN
Fact-Setup
> 3s
> 8s
2
5
Close
.. Use  button keypad as outlined in Steps  through 
to view or change parameter values.
Parameter
Description

AS
Installation type

rd
Reveal depth

Tb
Door width

dL
Door type
.. Configuration parameters.
Configuration parameters (Table ..) are set during
operator initial setup. Reference Chapter .
Table 9.2.1 Configuration parameters
. Configuration parameters
. Driving parameters
. ED – viewing and changing parameters
