30
ED900 09-2021DL4617-001
dormakaba ED900 Setup and Troubleshooting Instructions Chapter 12
Set track bumper stop
.. Set bumper stop position.
. Set Mode switch to OPEN.
. Door moves to set opening angle.
WARNING
Use caution when working in
proximity of door and track.
. Slide bumper and bumper stop toward
slide shoe until bumper is /" from
edge of slide shoe (Fig. ..).
. Tighten bumper stop M screw. Do not
overtighten.
CAUTION
Using Mode switch, close then
open door to verify gap between
bumper and slide shoe with door
at full open position.
. Set track bumper stop position
Fig. 12.1.2 Setting bumper stop location
Fig. 12.1.1 Mode switch
1 Slide shoe
2 Bumper
3 Bumper stop
4 M5 x 13 FHMS cross
recessed
1
2
3
4
3/16” gap
Open
