Dormakaba ED900 - Set Reveal Depth Parameter Rd

23
ED900 09-2021DL4617-001
dormakaba ED900 Setup and Troubleshooting Instructions Chapter 10
. Set reveal depth parameter rd

rd
Reveal depth
rd factory setting = .
Step 
Press
Scroll to rd parameter.
Step 
Press
Displays "" , factory setting.
Step 
Press
"" starts flashing.
Step 
Press
Scroll to "".
Step 
Press
Scroll to "".
Step 
Press
Saves value.
Display stops flashing.
Step 
Press
Returns to reveal depth parameter.
Step 
Go to Para. ., Set door type
parameter dL.
.. Set parameter rd, reveal depth = .
.. Measure reveal depth.
. Measure and record reveal depth.
• Reveal depth is set in increments of  mm
(approximately /"). Reference Table ...
TIPS AND RECOMMENDATIONS
Use of pull arm with CPD lever.
Value of parameter rd must be reduced by
/" [].
• Example: EDLE installation with reveal
of  mm ( /").
Parameter rd setting = 
(Reveal of  mm -  mm).
Fig. 10.6.1 Reveal depth parameter rd
.. Set rd reveal depth parameter value.
NOTICE
. If reveal depth = , set rd = .
• "" is rd factory setting.
• For system to recognize rd = , steps in
Para. .. must be followed.
. Set rd parameter to value other than .
• Follow steps in Para. ..
Step 
Press
Scroll to rd parameter.
Step 
Press
Displays "" , factory setting.
Step 
Press
"" starts flashing.
Step 
Press
Scroll to new value ("" as example).
Step 
Press
Saves value.
Display stops flashing.
Step 
Press
Returns to reveal depth parameter.
Step 
Go to Para. ., Set door type
parameter dL.
.. Set parameter rd to value other than .
