Dormakaba ED900 - Initial Setup - Pair Doors; Separately Setup Active and Inactive Doors; Set Operator Parameters for Pair Door Operation

28
ED900 09-2021DL4617-001
dormakaba ED900 Setup and Troubleshooting Instructions Chapter 11
.. Active door, set parameters dL and Ad.
. Set active door Mode switch to CLOSE.
. Set parameters dL (door type) and Ad (caster angle )
for active door.
• Castor angle sets opening angle of active door
before inactive door starts to open.
Factory setting is °.
Step 
Press
Press and hold PRG >  s to enter
program mode, AS parameter
displayed.
Step 
Press
Scroll to dL parameter.
Step 
Press
Displays "" , factory setting.
Step 
Press
"" starts flashing.
Step 
Press
Scroll to select parameter value
("" as an example).
Step 
Press
Saves value entered. Display stops
flashing.
Step 
Press
Returns to door type parameter.
Step 
Press
Scroll to Ad parameter.
Step 
Press
Displays "", factory setting.
Step 
Press
Scroll to select parameter value
(° as an example).
Step 
Press
Saves value entered. Display stops
flashing.
Step 
Press
Returns to caster angle parameter.
Step 
Press
Exits program mode. Operator is ready
for operation.
Door type
Parameter
value
Parameter description
* Single door

Pair door, with astragal.
Active door operator, door opens first.

Pair door, with astragal.
Inactive door operator.

Pair door, without astragal.
Active door operator. Both doors open
simultaneously.

Pair door, without astragal.
Inactive door operator. Both doors open
simultaneously.
*
Factory setting
CAUTION
Full width cover option.
Single program switch located on inactive
door.
. Separately setup active and inactive doors
 Initial setup – pair doors
.. Setup active door first.
. Refer to Chapter  and setup active door.
. Set operator parameters for pair door operation
.. Setup inactive door.
. Refer to Chapter  and setup inactive door.
Table .. Door type parameter dL values.
