Dover HEIL Half/Pack Factor AFL - Page 137

Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
131
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Y-Axis Positive direction
Activated
CAN
ON (CAN Control)
J05 Input Function – Joystick – X-AXIS (Negative Direction) (CAN – Cab Input)
1. Carry Can mode: Moving the Joystick Left (X-axis in Negative direction) makes the Curotto can Arm retract.
2. Manual mode: Moving the Joystick Left (X-axis in Negative direction) performs the Forks up operation.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
X-Axis Negative direction
Activated
CAN
ON (CAN Control)
J06 Input Function – Joystick – X-AXIS (Positive Direction) (CAN – Cab Input)
1. Carry Can mode: Moving the Joystick Right (X-axis in Positive direction) makes the Curotto can Arm extend.
2. Manual mode: Moving the Joystick Right (X-axis in Positive direction) performs the Forks down operation
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
X-Axis Positive direction
Activated
CAN
ON (CAN Control)
J07 Input Function – Joystick –Autolift Mode Button (CAN – Cab Input)
When the Auto Lift switch is ON and the Auto lift mode button (Red) is pressed it activates the Auto lift option i.e. press and
hold the Auto lift mode button (Red) and pull back the Joystick (Y- axis Negative direction), this lifts the Curotto can and
completes the Auto dump cycle.
Press and hold the Auto lift mode button (Red) and push the Joystick forward (Y- axis Positive direction), this makes the
Curotto can roll out of the Hopper and brings the Arms to down position.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
