Section 1: CORTEX32 Controller Hardware
1.01: CORTEX32 Controller Indicator Lights
The 2018 Dedicated Half/Pack Factor AFL vehicle control system consists of 3 CORTEX32 Controllers. The “MAIN”
CORTEX32 Controller is an Extended Controller consisting of 80 Inputs / Outputs, the Remote Tailgate CORTEX32
Controller (“RTG”) and the Remote Can CORTEX32 Controller (“RCN”)* is a Standard Controller consisting of 32 Inputs /
Outputs. The CORTEX32 controllers operates with a voltage ranging from (8 to 32) Volt DC. Each CORTEX32 Controller
has a three-color LED (Red / Green / Blue) which indicates the current status of the Controller. The LED operating status
identifications are detailed in the table below.
Note*: The Remote Can CORTEX32 Controller (“RCN”) is a Standard Controller consisting of 32 Inputs / Outputs which is
used as a DEDICATED remote Can controller on Residential units.
CORTEX32 CONTROLLER DETAILS
Controller No.
Controller Type
Controller Location
Controller Name
1.
CORTEX32 CR0233
StreetSide Body Side Skirt (Middle)
(Main) Main Controller
2.
CORTEX32 CR2530
StreetSide Body Side Skirt (Rear)
(RTG) Remote Tailgate Controller
3.
CORTEX32 CR2530
Dedicated Can Street Side (Rear)
(RCN) Remote Can Controller
LED Color
Status
Description
OFF
OFF
No Operating Voltage
Yellow
1 x ON
Initialization or Reset Checks
Orange
ON
Error in start-up phase
Green
5.0 Hz
No Operating System Loaded
Green
2.0 Hz
ON
Run
Stop
Red
2.0 Hz
ON
Run with Error
Fatal Error or Stop with Error
Red
3
5.0 Hz
ON
Application Stopped due to under Voltage.
Fatal Error System fault
Blue
1,2
2.0 Hz*
Communication OK between 2 Controllers (for 80 I/O CORTEX32
Controller)
1
.
Communication OK between Main, RCN and RTG Controllers (for 32 I/O
CORTEX32 Controller Only)
2
Note
1
: LED will flash Blue when there is a good communication between the 2 halves of the Controller. This condition is
applicable only for 80 I/O CORTEX32 Controllers.
Note
2
: LED will flash Blue when there is a good communication between the MAIN, RTG and RCN Controllers. This
condition is applicable only for 32 I/O CORTEX32 Controllers.
