STANDARD TORQUE DATA FOR NUTS AND BOLTS TABLE
Bolt Size
(D)
Nut Type
(STD/Lock)
Thread
Turns per
Inch
(p)
Grade
Heil Plain Dry
Condition
Torque Value
(ft-lbs)
Heil Zinc
Plated
Fastener
Torque
Value
(ft-lbs)
Heil
Lubricated
Fastener
Torque Value
(ft-lbs)
Heil
Deformed
Lock Nut
Torque Value
(ft-lbs)
18
5
120
8
169
3/4
STD
10
5
288
260
188
0.750
8
408
367
265
16
5
322
290
209
8
455
409
295
Lock
10
5
188
8
265
16
5
209
8
295
7/8
STD
9
5
465
418
302
0.8750
8
657
591
427
14
5
513
461
333
8
724
652
471
Lock
9
5
302
8
427
14
5
333
8
471
1
STD
8
5
697
627
453
1.0000
8
984
886
640
14
5
782
704
508
8
1105
994
718
Lock
8
5
453
8
640
14
5
508
8
718
1-1/8
STD
7
5
869
782
565
1.1250
8
1395
1256
907
12
5
975
877
634
8
1564
1408
1017
Lock
7
5
565
8
907
