Half/Pack
®
Issued April 2018
Compressed Natural Gas (CNG) Option
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Compressed Natural Gas (CNG) Option
195
CNG FUEL MODULE TROUBLESHOOTING (CONTINUED)
The following table lists possible problems, along with causes, corrections, and results.
PROBLEM OBSERVED
POSSIBLE CAUSES
CORRECTIVE/DIAGNOSTIC
ACTIONS
RESULTS AND OTHER
ACTIONS
Heil Standard CNG and
Solenoid System
Options:
In-cab fuel gauge does not
indicate the fuel level
correctly.
The fuel module pressure
transducer, the fuel gauge
or the interconnecting
wiring may be defective.
Confirm that the 12-pin
electrical connector at the rear
of the fuel module is connected
and place the vehicle's ignition
switch in the "Run" position.
Use a voltmeter to read:
Voltage between connector
positions 2 (RED) and 3
(BLK). the voltage should be
12 vdc.
Voltage between connector
positions 3 (BLK) and 4
(WHT). the voltage should be
between 0.5 to 5.0 vdc.
*If the voltage across 2
and 3 is 0 or significantly
below battery voltage,
there is a problem with the
vehicle's wiring not
supplying power to the fuel
module's pressure
transducer.
*If the voltage across 3
and 4 is either 0 or 5.5 vdc,
the fuel module's pressure
transducer is most likely
defective. Call 866-310-
4345 for technical
assistance.
*If the voltage across 3
and 4 is between 0.5 to 5.0
vdc then the fuel module's
pressure transducer is
operating correctly. The
problem is likely in the
vehicle's wiring or the in-
cab fuel gauge.
*If the problem cannot be
resolved, call 866-310-
4345 for technical
assistance.
Solenoid System Option:
In-cab Cortex Display does
not indicate the fuel level
correctly or an alarm is
activated on the Cortex
Display indicating
"Transducer-# Unplugged/
Short Check Sensor and
Wiring" Fail for a given
Tank#.
The fuel cylinder pressure
transducer or the
interconnecting wiring may
be defective.
Confirm that the 3pin electrical
connector at the transducer is
connected and place the
vehicle's ignition switch in the
"Run" position. Use a voltmeter
to read:
Voltage between connector
positions A (BRN) and B
(BLK). The voltage should be
approximately 12 vdc.
Voltage between connector
positions B (BLK) and C
(YEL). The voltage should be
between 0.5 to 5.0 vdc.
*If the voltage across A
and B is 0 or significantly
below battery voltage,
there is a problem with the
vehicle's wiring not
supplying power to the fuel
module's pressure
transducer.
*If the voltage across B
and C is either 0 or 5.5
vdc, the fuel tank's
pressure transducer is
most likely defective. Call
866-310-4345 for technical
assistance.
*If the voltage across B
and C is between 0.5 to
5.0 vdc then the fuel
module's pressure
