CYLINDER SENSORS CALIBRATION (CONTINUED)
NOTICE
The arms, forks and packer will move very, very slow due to the unit being in Calibration Mode.
2. Perform the calibration steps below.
a. Place Arms all the way DOWN and fully retract the Packer Blade – press OK (the display will move to the next
screen)
b. Raise the arms to just below the top of the windshield – press OK (this is the arms interlock position, 47°)
c. Raise the arms to the forks roll position (as shown on the display, 72°) – press OK
d. Raise the arms to the fully raised position – press OK (this is the arms fully raised position)
e. Lower the arms all the way down.
f. Lower the forks parallel to the ground (load position, 82°) – press OK
g. Raise the forks to the Forks Clear position (70°) – press OK
h. Extend the packer manually to the end of the first stage of the cylinder – Press OK (this is the packer fully
extended position)
i. Extend the packer to just inside the body – press OK (this is the packer travel position)
j. At this point the truck is calibrated and pressing OK finishes the sequence.
