Dover HEIL Half/Pack Factor AFL - Page 88

Half/Pack
®
Issued April 2018
Body Controller Hardware
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Hardware
82
ITEM
PART NUMBER
DESCRIPTION
QTY
NOTES
-
474-0004-003
KIT, UNIT, DEDICATED CAN
REF
1
047-2151-011
1/4" 14X11" LG TEK SCREW #3
2
2
047-2621-375
SCREW, BUTTON, HEAD CAP
8
-3
054-5449-A
1/4" O.D. BLACK AIR LINE
1
4
054-8470-004
AIR LINE CONNECTOR ELBOW
2
5
075-0721
FILTER/REGULATOR W/GAUGE
1
6
108-7691
ROCKER SW, MAINTAINED, DPST
1
7
108-8626-241
SWITCH ACTUATOR, DUAL CONTROLS
1
8
211-9967
AIR FILTER/REGULATOR BRACKET
1
9
234-3374
PLATE, RAIN SHIELD MAIN CONTROLLER
1
10
234-3374-001
PLATE, RAIN SHIELD T/G CONTROLLER
1
11
254-4897
80 10, 32 BIT
1
12
254-4912-001
MODULE, CORTEX REMOTE 32 I/O
VARIOUS
2
-13
263-1738-004
HARNESS, JOYSTICK SPLITTER, AFL
1
-14
263-1815-003
HARNESS, ODYSSEY CONTROL PANEL,
2018 AFL HP/ODY
1
-15
263-1815-004
HARNESS, ODYSSEY VALVE OVERLAY,
2018 AFL HP/ODY
1
-16
263-1815-008
HARNESS, ODYSSEY ARM, 2018 AFL HP/
ODY
1
17
311-5666
BRACKET, MOUNTING, FUSE BLOCK
1
18
311-6232
PANEL, CONTROLLER MOUNT
1
19
311-6304
BRACKET, CONTROLLER BODY SIDE
1
20
FSP230400
LOCKNUT, #10 UNC GR, PLATED
8
21
FSP320700
NUT, 1/4" UNC GR8, PLATED
2
22
FSP420711
MACHINE SCREW 1/4"-20 NC X 1/2, PLATED
2
23
FSP510400
WASHER, FLAT, #10 STD, PLATED
8
24
FSP510700
WASHER, FLAT, 1/4" STD, PLATED
2
25
FSS230700
LOCKNUT, 1/4" UNC STAINLESS STEEL
13
