Dover Wayne Select S1 - C.2 Pulse Output Interface Board Layout

56 Dover Fueling Solutions W2940305 Rev 07 8/2019
17 5/8 in.
[448.1 mm]
9 7/8 in.
[251.8 mm]
19 7/8 in.
[503.6 mm]
21 5/8 in.
[548.8 mm]
20 1/2 in.
[519.5 mm]
23 3/8 in.
[592.9 mm]
47 7/8 in.
[1215.0 mm]
59 1/4 in.
[1505.0 mm]
Units w/
iX Fleet
Front View
Right Side View
Holes for
mounting
shelf bracket
Holes for
mounting
Breakaway
4 in.
[101.7 mm]
7 in.
[177.8 mm]
4 in.
[101.6 mm]
1 3/8 in.
[35.3 mm]
Models: Shelf Bracket
