Dover Wayne Select S1 User Manual

82 Dover Fueling Solutions W2940305 Rev 07 8/2019
E.12 Configuration Functions
 Following is a complete list of configuration functions and sub-functions. The
Configuration Setting column shows the default settings loaded at the factory. Note some
settings differ if the pulse output interface option is ordered. Any settings which differ
based on the model are referenced to a model table at the end of the list. “N” shown in
the Sub-Function number represents the logical nozzle number. For most of these
applications, that will be “1”.
Function Number & Name Sub-function Number & Description
Configuration
Setting
Std.
Model
w/ Pulse
Output
F - - Function Level N/A Alternates software revision number and date
F00 Exit Function .00 1 = Do not exit and do not save changes
2 = Exit, but do not save changes
3 = Exit and save changes
F01 Filling Modes .00 1 = Serial mode, dispenser controlled by site
controller serial link
2 = Stand Alone Mode, dispenser not
supervised by a site controller w/ serial
link (used for standalone and pulse
output interface)
3 = Serial W&M Mode, same as #1 but vol
decimal point format forced to .xxx vol
units
4 = Stand Alone W&M Mode, same as #2
but vol decimal point format forced to
.xxx vol units
2 (Standalone &
POB option)
1 (iX Fleet option)
F02 Clock Configuration .00 Time in the format HH.MM
.01 Date in the format MM.DD
.02 Year in the format YYYY
F03 Set Side A Unit Prices .0N Set credit price 0
.1N Set cash price 0
F04 Set Side B Unit Prices .0N Set credit price 0
.1N Set cash price 0
F05 Set Side A Fueling Point
Address
.00 Fueling point address, 0–31, where 0=none
assigned
0 (1 for iX Fleet
option)
F06 Set Side B Fueling Point
Address
.00 Fueling point address, 0–31, where 0=none
assigned
0 (2 for iX Fleet
option)
F07 Dispenser Configuration .00 Max. logical nozzle number for each side, 1-
8
1
.01 Dispenser geometry
1 = single-sided
2 = double-sided
see model chart at
end
.02 Max. blend error allowed, 1-5 (units of %) 2
.03 First check set for blending if liters, 2-200
(units of 1/10 liters)
50
.04 First check set for blending if gallons, 5-50
(units of 1/10 gallons)
12
.05 Reserved
.06 Reserved
