Dover Wayne Select S1 User Manual

W2940305 Rev 07 8/2019 Dover Fueling Solutions 83
Function Number & Name Sub-function Number & Description
Configuration
Setting
Std.
Model
w/ Pulse
Output
.07 Stop button configuration
1=Stop both sides
2=Stop side
2
.08 Number of displays per side
0=one display per side
1=Second display on Side A
2=Second display on Side B
3=Second display on Sides A & B
0
.09 Error indication on display
0=Show CLOSED for error levels 2,3,4
1=Show CLOSED for error levels 2,3,4 &
show error code for error levels 2,3,4
2=Show CLOSED for error levels 2,3,4 &
show error code for error levels 1,2,3,4
3=Show CLOSED for error levels 2,3,4 &
show error code for error levels 0,1,2,3,4
0
F08 Side A Dispenser Type
Configuration Part #1
.0N Physical nozzle number assignment, 0–8, 0
= none assigned
.01=1
.1N Product type assignment, 1 = non-blend, 2 =
blend
.11=1
.2N Unit price display assignment, 0–8, 0 = none
assigned
.21=1
.3N Primary meter number assignment, 0-8, 0 =
none assigned
.31=1
.4N Secondary meter number assignment, 0-8, 0
= none assigned
see model chart at
end
.5N Primary valve number assignment, 0-8, 0 =
none assigned
.51=1
.6N Primary valve type
1=on/off
2=proportional
3=Two stage UHC ASCO
4=Two stage UHC Parker
.61=2 (3 or 4 for
UHC models)
.7N Secondary valve number assignment, 0-8, 0
= none assigned
see model chart at
end
.8N Secondary valve type
1=on/off
2=proportional
3=Two stage UHC ASCO
4=Two stage UHC Parker
.81=2
F09 Side B Dispenser Type
Configuration Part #1
.0N Physical nozzle number assignment, 0–8, 0
= none assigned
.01=1
.1N Product type assignment, 1 = non-blend, 2 =
blend
.11=1
.2N Unit price display assignment, 0–8, 0 = none
assigned
.21=1
.3N Primary meter number assignment, 0-8, 0 =
none assigned
.315
(2 for /8 models w/
two 1/2 iMeters)
.4N Secondary meter number assignment, 0-8, 0
= none assigned
see model chart at
end
.5N Primary valve number assignment, 0-8, 0 =
none assigned
.51=5
.6N Primary valve type
1=on/off
2=proportional
3=Two stage UHC ASCO
4=Two stage UHC Parker
.61=2 (3 or 4 for
UHC models)
