E.10 List of Statistics
 Following is a complete list of statistics and diagnostics available in the Select dispenser
series. Statistics identified as “Side B” only apply to twin units with two hoses.
 Statistics identified as “Totals” are resettable and statistics identified as “Totalizers” are
non-resettable.
Statistic
No. Statistic Name
Sub-Statistic
No. Sub-Statistic Description
S - - Statistics Entry Point N/A Transaction count for Side A (alternates)
S 01 Side A Totals
1.11 Volume total
1.21 Money total
1.51 Serial filling mode filling count ( Wayne protocol)
1.61 Stand alone mode filling count (standalone or pulse output)
S 02 Side B Totals
2.11 Volume total
2.21 Money total
2.51 Serial filling mode filling count ( Wayne protocol)
2.61 Stand alone mode filling count (standalone or pulse output)
S 03
Side A Error/Event
Counter Totals
3.1 - 3.99
Sub-statistic = error/event code (1 – 99) with counter value
0-255
S 05
Side A Meter Volume
Totals
5.M0
Meter volume totals
(M = meter #. Use the NEXT key to scroll through sub-
functions to the meter number(s) for your desired model or
reference the functions list for meter assignments. SHC
models have two meters per hose.)
Note: See Meter Number Assignments table at the end of
section to determine the meter numbering for your model.
S 11 Side A Totalizers
11.11 Volume totalizer
11.21 Money totalizer
11.51 Serial filling mode filling count ( Wayne protocol)
11.61 Stand alone mode filling count (standalone or pulse output)
S 13
Side A Error/Event
Counter Totalizers
13.00- 13.99
Sub-statistic = error/event code (1 – 99). Maintains counter
0-999.
S 15
Side A Meter Volume
Totalizers
15.M0
Meter volume totalizer
(M = meter #. Use the NEXT key to scroll through sub-
functions to the meter number(s) for your desired model or
reference the functions list for meter assignments. SHC
models have two meters per hose.)
Note: See Meter Number Assignments table at the end of
this section to determine the meter numbering for your
model.
S 17
Side A WIP (Pulser)
Volume Totalizers
17.M0
WIP volume totalizer
(M = meter #. Use the NEXT key to scroll through sub-
functions to the meter number(s) for your desired model or
reference the functions list for meter assignments. SHC
models have two meters per hose.)
Note: See Meter Number Assignments table at the end of
this section to determine the meter numbering for your
model.
