W2940305 Rev 07 8/2019 Dover Fueling Solutions 111
Appendix H: iX Fleet Fuel Control System
H.1 General
An iX Fleet Fuel Control System can be provided as an option for controlling a Select S1
Compact Electronic Dispenser. When supplied from the factory, the iX Fleet In-Dispenser
Terminal (IDT) and all internal connections to control the dispenser will be in place. The iX
Fleet Operation manual (P/N 000-W2940084-) covers the operation of the system. This
Appendix covers items specific to field installation of the wiring between the iX Fleet IDT and
the iX Fleet Controller or LAN.
H.2 Power Requirements
Power for the iX Fleet system is supplied directly from the same AC power source that is
used to power the dispenser (Control Power). The following adder must be considered for
sizing the AC wiring and breaker for the dispenser in addition to the power requirements of
the dispenser:
iX Fleet 120VAC 50/60 Hz 4.7 Amp
H.3 Ethernet Connection
When connecting the iX Fleet system directly through an Ethernet cable (either directly to the
iX Fleet Fuel Controller or through a LAN/WAN), a hardwired connection must be made to the
dispenser(s). To meet code and for proper operation, the following must be adhered to:
Standards For trouble-free operation, Ethernet cable should be installed by a qualified
telecommunications technician in accordance with ANSI/TIA/EIA 568-A
Commercial Building Telecommunication Cabling Standards (and
Amendments). It is highly recommended that for other than very simple site
layouts or for when the systems will be connected to an existing LAN/WAN, a
qualified engineer be used to design the network for this system. Network
wiring should be tested according to ANSI/TIA/EIA TSB 67 prior to use.
Cable As the cable for this connection is passing through a fuel island hazardous
area, a cable that is rated for such use must be used. The following cables are
rated to be oil and gas resistant:
Belden 7928A Category 5e cable
Belden 7931A Category 6 cable
Madison 042GA00006 Category 5 cable*
*
Note: Madison Ethernet cable can be purchased from DFS using Part Number 891052-
002. The cable can be purchased in 500 feet increments.
iX Fleet The iX Fleet Fuel Controller is the common control device for the site(s).
Fuel A controller can be used to control any dispenser that is either directly
Controller connected to the controller or connected to the controller via the Local Area
Network (LAN). Remote sites without LAN access require the use of an
additional iX Fleet Fuel Controller. Controllers operate independent of each
other meaning they require separate employee and vehicle entries as well as
generating separate reports.
Dispensers
Dispensers with iX Fleet IDTs must be directly connected to the iX Fleet Fuel
Controller, can be connected to the controller via an Ethernet switch, or can be
connected via a LAN. Dispensers can also be interconnected with each other
before the Ethernet connection is routed back to the iX Fleet Fuel Controller.
