W2940305 Rev 07 8/2019 Dover Fueling Solutions 65
CAT Ethernet
Field Wiring
Dispenser Current Loop
Field Wiring
Forecourt
Controller
POS
TCP
Gallons
$
$ Price Per Gallon $ Price Per Gallon
$
Gallons
TCP
Ethernet Port
Switch
TCP
iX Gateway
TCP
Router
Modem
TCP
TCP
Site Layout D
Dispenser: Current Loop
Payment Terminal: Ethernet via Hardwired Connection
This configuration will only work for Payment Terminals (CATs) running in the EMV mode. It can also
handle Wayne iSense
TM
remote monitoring, Wayne iX Media
TM
platform, and Wayne inOvationTV
TM
media.
