Dover Wayne Select S1 User Manual

74 Dover Fueling Solutions W2940305 Rev 07 8/2019
T568B
T568
A
1234
5
678
Pair 2
Pair 3
Pair 2
Pair 3
876543
21
Ora Ora/Wht
Grn Grn/Wht
Grn/Wht Grn Ora Ora/Wht
Termination After the Ethernet cable has been pulled into the dispenser, it must be
terminated with an RJ45 jack. Two wire schemes are shown below. Most
applications use T568A. Either wiring scheme can be used as long as the
same scheme is used at both ends of the cable. RJ45 connectors and
crimpers can be purchased at hardware and electronic chain stores.
Pin
T5
68
A
Pair T568A Color
T5
68
B
Pair T568B Color
13
green striped
2
orange striped
23
green
2
orange
32
orange striped
3
green striped
41 1
51 1
62
orange
3
green
74 4
84 4
Pin 1 Pin 8
Cli
p
on to
p
Crimping Tool
