Dräger Infinity Series User Manual

Alarms and Messages
VF4 Infinity Gamma Series Page 5-3
Serious Alarms
A serious alarm has the second highest priority. It alerts you to
significant changes in the patient’s condition other than life-
threatening events as defined in the preceding section. For exam-
ple, if a monitored parameter falls below the selected alarm lim-
its, the monitor triggers a serious alarm. An unrecognized
physiological condition, as when a detected parameter is outside
the monitor’s measuring range, triggers a serious alarm also.
NOTE: Apnea events trigger a serious alarm in all monitoring
modes.
A serious alarm has the following characteristics:
! The parameter box blinks and appears yellow.
! The monitor produces two short tones continuously.
! The monitor displays the alarm cause in both the parameter
box and the message area.
! The monitor stops the alarm automatically when the condi-
tion ceases to exist.
! The monitor stops the alarm when a new alarm of equal or
higher grade is triggered.

Dräger Infinity Series Specifications

General

Manufacturer	Dräger
Device Type	Patient Monitor
Weight	5 kg to 10 kg (depending on the model and configuration)
Connectivity	Ethernet, USB, WLAN (optional)
Parameters Monitored	ECG, SpO2, NIBP, Temperature, Respiration
Alarm System	Visual and audible alarms, customizable alarm limits
Device Category	Medical Device
Series	Infinity
Display	Color TFT
Display Size	12.1 inches
Power Supply	AC Power, Internal Battery
Battery Life	Up to 4 hours (depending on configuration)
