Dräger Infinity Series User Manual

Network Applications
VF4 Infinity Gamma Series Page 3-3
Network Configurations
A basic Infinity network includes:
! Bedside monitors.
! A central station (MULTIVIEW WORKSTATION).
! Docking stations at the bedside.
! R50 Series recorders.
! Infinity network cabling and repeater hubs.
A basic Infinity wireless network includes:
! Bedside monitors.
! A central station (MULTIVIEW WORKSTATION).
! Wireless LAN PC Cards.
! Access points with antennae.
! R50 Series recorders.
! Infinity network cabling and repeater hubs.
Dräger offers a large variety of network components and supplies
that allow you to customize your hospital’s network configura-
tion. Network setup and configuration are Service functions per-
formed during installation. Please see your local Dräger
representative for details.
NOTE: A Care Unit is a group of beds with the same hospital-
assigned identification (i.e. CCU, ICU). The name of a Care Unit is
unique within the hospital. A Monitoring Unit is a logical group of
beds that share certain monitoring functions, such as alarm annun-
ciations, recordings, and remote views. A Monitoring Unit can have
more than one central station and span more than one Care Unit.

Dräger Infinity Series Specifications

General

Manufacturer	Dräger
Device Type	Patient Monitor
Weight	5 kg to 10 kg (depending on the model and configuration)
Connectivity	Ethernet, USB, WLAN (optional)
Parameters Monitored	ECG, SpO2, NIBP, Temperature, Respiration
Alarm System	Visual and audible alarms, customizable alarm limits
Device Category	Medical Device
Series	Infinity
Display	Color TFT
Display Size	12.1 inches
Power Supply	AC Power, Internal Battery
Battery Life	Up to 4 hours (depending on configuration)
