Dräger Infinity Series User Manual

Page 10-8 Infinity Gamma Series VF4
ST Alarms
Set ST alarm limits on the Alarm Limits table (see the chapter
Alarms and Messages). The default ST segment deviation alarm
limits are +1.0 mm (or +0.10 mV) for the upper limit and -1.0
mm (or -0.10 mV) for the lower limit. However, adjustments to
the upper and lower alarm limit settings must be made based on
careful clinical evaluation. You can set the upper and lower lim-
its within the following range:
! -15.0 mm to +15.0 mm, in 0.1 mm increments (-1.5 mV to
+1.5 mV, in 0.01 mV increments, when using millivolts.)
NOTE: Always check the upper and lower ST alarm limits before
starting ST monitoring.

Dräger Infinity Series Specifications

General

Manufacturer	Dräger
Device Type	Patient Monitor
Weight	5 kg to 10 kg (depending on the model and configuration)
Connectivity	Ethernet, USB, WLAN (optional)
Parameters Monitored	ECG, SpO2, NIBP, Temperature, Respiration
Alarm System	Visual and audible alarms, customizable alarm limits
Device Category	Medical Device
Series	Infinity
Display	Color TFT
Display Size	12.1 inches
Power Supply	AC Power, Internal Battery
Battery Life	Up to 4 hours (depending on configuration)
