Dräger Infinity Series User Manual

Page 13-18 Infinity Gamma Series VF4
STEPS: Entering Atmospheric Pressure Values
Manually
1. Click on the etCO
2
parameter box.
2. Click on
More...
3. Click on Atm. Pressure.
4. Dial in the current barometric pressure value.
NOTE: Atmospheric pressure values can be read from a barometer
or obtained by calling the closest weather station.

Dräger Infinity Series Specifications

General

Manufacturer	Dräger
Device Type	Patient Monitor
Weight	5 kg to 10 kg (depending on the model and configuration)
Connectivity	Ethernet, USB, WLAN (optional)
Parameters Monitored	ECG, SpO2, NIBP, Temperature, Respiration
Alarm System	Visual and audible alarms, customizable alarm limits
Device Category	Medical Device
Series	Infinity
Display	Color TFT
Display Size	12.1 inches
Power Supply	AC Power, Internal Battery
Battery Life	Up to 4 hours (depending on configuration)
