nl | Beschrijving
224 X-am
®
2800 / X-am
®
5800
3 Beschrijving
3.1 Productoverzicht
Markering van verrekende kanalen (alleen X-am 5800):
49783
Grafiek A
1 Gasinlaat 8 IR-interface
2 Alarm-LED 9 Bevestigingsclip
2a D-Light 10 Typeplaatje
3 Hoorn 11 Laadcontacten
4
-toets
12 Meetgasdisplay
5 Voeding 13 Meetwaardedisplay
6
-toets
14 Speciale tekens
7 Display 15 Inbussleutel
(2 mm; alternatief: Torx T8)
Functie Weergave op het display
Toxic Twins HCN+
OK
2
1
7
6
4
5
3
2
9
11
12 13 14
8
10
2a
15
OK
