Dräger MQG 02 0 Series User Manual

en | Description
44 X-am
®
2800 / X-am
®
5800
3 Description
3.1 Product overview
Marking added-signal channels (X-am 5800 only):
49783
Graphic A
1 Gas inlet 8 IR interface
2 Alarm LED 9 Fastening clip
2a D-Light 10 Name plate
3 Horn 11 Charging contacts
4
key
12 Measured gas display
5 Power pack 13 Measuring value display
6
key
14 Special symbols
7 Display 15 Allen key
(2 mm; alternative: Torx T8)
Feature Shown in display
Toxic Twins HCN+
OK
2
1
7
6
4
5
3
2
9
11
12 13 14
8
10
2a
15
OK
