3.5
Test
015:
Reading
in
the
Analog
Channels
You
can
display
the
desired
analog
channel
by
pressing
the
Info
key
or
the
Reset
key.
The
displayed
measured
value
is
continually
re-calculated.
A
total
of
eighteen
values
are
displayed.
The
measured
value
is
shown
in
LSB
(1023
LSB
correspond
to
5.0
V).
•
Select
the
Extended
Service
Mode
(ESM).
•
Press
the
Reset
key
or
the
Info
key
to
select
Test
015.
•
Press
the
Info
key
and
the
Reset
key
simultaneously
to
activate
Test
015.
Caution:
The
values
shown
in
the
following
table
apply
to
an
operational
Oxylog
2000
equipped
with
a
fully
charged
and
connected
rechargeable
battery
pack.
DS-Modus
5503.160
Oxylog
2000
11/97
Service-Mode
SW
2.xx
Page
27
