Advanced Configuration Features
39
Horizon Compact Release 1.01.00 Wireless Ethernet Product User Manual – Volume 2
Required Action Steps
set cos expedite queue Enables or disables the expedite queue function. Expedite queues are
processed first, prior to any other queue being processed. This allows
the user to force the system to transmit high priority traffic before lower
priority traffic.
Sequence:
set cos expedite queue [on/off]
The system responds:
Expedite queue is :on/off
set cos queue cir [%1 %2 %3
%4]
Sets the Committed Information Rate (CIR) for each of the 4 CoS
Queues. The CIR defines the minimum amount of bandwidth allocated
for that Queue. Note that Queues set as Expedite Queues can
override the CIR for other Queues should congestion occur.
Sequence:
set cos queue cir [%1 %2 %3 %4] press Enter
where %1 %2 %3 %4 is the percentage of the total Queue memory to
be allocated to CoS Queues 1 through 4 respectively. The total
cannot exceed 100% unless Expedite Queuing has been enabled.
The system responds: (example shown using 25% settings for each
queue)
Expedite queue is :off.
All queues bandwidth are guaranteed.
Queue CIR(%) CIR(Mbps)
1 25 25
2 25 25
3 25 25
4 25 25
If Expedite Queuing has been enabled, then each queue that has been
configured for 100% CIR is treated as an Expedite Queue.
Sequence:
set cos queue cir 25 100 25 100
The system responds:
Expedite queue is :on
Bandwidth for higher priority queues are guaranteed over
lower priority queues
Queue CIR(%) CIR(Mbps)
1 25 25
2 100 Full
3 25 25
4 100 Full
“Full” indicates that the queue is an Expedite Queue and can consume
the full bandwidth of the Horizon Compact.
