DragonWave Inc. 72
Horizon Compact Release 1.01.00 Wireless Ethernet Product User Manual – Volume 2
Procedure 3-14
Configure Rapid Link Shutdown Options
Perform this procedure to configure the Rapid Link Shutdown Options for the Horizon Compact system.
When RLS is used, the Horizon Compact Port 1 will be set to "down" during modem-to-modem
communication failure. This feature allows a router to select an alternate path should the modem-to-
modem communications fail.
Note: To perform this procedure, you must have NOC user rights.
Required Action Steps
login Log in as a NOC user.
get rls Displays the state of the Rapid Link Shutdown feature. RLS provides
the ability to shut down the Horizon Compact Ethernet link (both
endpoints) during system outages.
The default is "off".
Sequence:
get rls press Enter
The system responds:
RLS option is :[off/on].
rls status Displays the detailed status of the RLS configuration.
Sequence:
get rls status press Enter
The system responds (Example):
RLS Option: On Advanced
Rapid Link Shutdown: Activated
RLS Peer Mismatch: Activated
Degrade Monitor State: Activated
Hard Fault Monitor State: Acitvated
Make RSL Threshold: OK
Peer RLS State: OK
Radio Interface State: Up
Network Interface State: Down
User Configured Establish FER: 8.82E-07
Minimum Achievable Establish FER: 3.06E-07
User Configured Shutdown FER: 1.76E-04
Minimum Achievable Shutdown FER: 3.06E-06
User Configured Establish Monitor Time(mSec): 40000
Actual Establish Monitor Time(mSec): 45517
User Configured Shutdown Monitor Time(mSec): 3000
Actual Shutdown Monitor Time(mSec): 4550
