Vigor2862 Series User’s Guide
101
the system to execute for WAN detection. If you choose Ping
Detect as the detection mode, you have to type required
settings for the following items.
Primary/Secondary Ping IP – If you choose Ping Detect as
detection mode, you have to type Primary or Secondary IP
address in this field for pinging.
Ping Gateway IP – If you choose Ping Detect as detection
mode, you also can enable this setting to use current WAN
gateway IP address for pinging.
With the IP address(es) pinging, Vigor router can check if
the WAN connection is on or off.
TTL (Time to Live) – Set TTL value of PING operation.
Ping Interval – Type the interval for the system to
execute the PING operation.
Ping Retry – Type the number of times that the system is
allowed to execute the PING operation before WAN
disconnection is judged.
MTU It means Max Transmit Unit for packet.
AP Discovery Click this button to open the Access Point Discovery window.
Let wireless 2.4GHz do AP discovery and choose the Wireless
AP you wan to connect to.
SSID The identification of the Wireless AP.
MAC Address (Optional) The MAC Address of the Wireless AP.
Channel The channel of frequency of the Wireless AP. Please notice
that, if this setting is modified, the channel of Wireless LAN
(2.4GHz) would be also modified.
Security Mode The mode to connect to the Wireless AP.
Disable – The Router connects to the wireless AP without any
encryption mechanism.
WEP – The Router connects to the wireless AP as a WEP client
and the encryption key should be entered in WEP Key.
64-Bit - For 64 bits WEP key, either 5 ASCII characters,
such as 12345 (or 10 hexadecimal digitals leading by 0x,
such as 0x4142434445.)
128-Bit - For 128 bits WEP key, either 13 ASCII
characters, such as ABCDEFGHIJKLM (or 26 hexadecimal
digits leading by 0x, such as
0x4142434445464748494A4B4C4D).
WEP keys – Four keys can be entered here, but only one
key can be selected at a time. The keys can be entered
To Next Page
