Magnetic antenna must be installed on the extension base before connecting to Vigor router.
There are two mounting holes for installing antennas with extension base on Vigor router.
Please install them as shown below.
Note, if only one antenna shall be installed, please use the mounting hole (major signal
transmitted hole) near to the SIM card slot.
Extension Base
Extension Base
SIM Card
Slot
Major Signal
Transmitted Hole
