Vigor2862 Series User’s Guide
41
I
I
-
-
6
6
-
-
2
2
F
F
o
o
r
r
W
W
A
A
N
N
2
2
(
(
E
E
t
t
h
h
e
e
r
r
n
n
e
e
t
t
)
)
/
/
(
(
W
W
i
i
r
r
e
e
l
l
e
e
s
s
s
s
2
2
.
.
4
4
G
G
)
)
WAN2 can be configured for physical mode of Ethernet or Wireless 2.4G. If you choose
Ethernet WAN2, please specify a physical type. Then, click Next.
Available settings are explained as follows:
Item Description
Display Name Type a name for the router.
Physical Mode Choose Ethernet or Wireless based on the physical
connection.
Choose Wireless 2.4G if you want to use wireless station
mode to access Internet. Otherwise, choose Ethernet to
access Internet through WAN2 Ethernet Port.
Physical Type This setting is available when Ethernet is selected as
Physical Mode. In general, Auto negotiation is suggested.
VLAN Tag insertion The settings configured in this field are available when
Ethernet is selected as Physical Mode.
Disable – Disable the function of VLAN with tag.
Enable – Enable the function of VLAN with tag.
The router will add specific VLAN number to all packets on
the WAN while sending them out.
Please type the tag value and specify the priority for the
packets sending by WAN2.
Tag value – Type the value as the VLAN ID number. The
range is form 0 to 4095.
Priority – Type the packet priority number for such
VLAN. The range is from 0 to 7.
On the next page as shown below, please select the appropriate Internet access type
according to the information from your ISP. For example, you should select PPPoE mode if the
ISP provides you PPPoE interface. Then click Next for next step.
