Vigor2862 Series User’s Guide
103
3G /4G USB Modem (PPP
mode)
Click Enable for activating this function. If you click Disable,
this function will be closed and all the settings that you
adjusted in this page will be invalid.
SIM PIN code Type PIN code of the SIM card that will be used to access
Internet.
The maximum length of the PIN code you can set is 15
characters.
Modem Initial String Such value is used to initialize USB modem. Please use the
default value. If you have any question, please contact to
your ISP.
The maximum length of the string you can set is 47
characters.
APN Name APN means Access Point Name which is provided and
required by some ISPs. Type the name and click Apply.
The maximum length of the name you can set is 43
characters.
Modem Initial String2 The initial string 1 is shared with APN.
In some cases, user may need another initial AT command to
restrict 3G band or do any special settings.
The maximum length of the string you can set is 47
characters.
Modem Dial String Such value is used to dial through USB mode. Please use the
default value. If you have any question, please contact to
your ISP.
The maximum length of the string you can set is 31
characters.
Service Name Enter the description of the specific network service.
PPP Username Type the PPP username (optional). The maximum length of
the name you can set is 63 characters.
PPP Password Type the PPP password (optional). The maximum length of
the password you can set is 62 characters.
PPP Authentication Select PAP only or PAP or CHAP for PPP.
Schedule Profiles Set the wireless LAN to work at certain time interval only.
You may choose up to 4 schedules out of the 15 schedules
pre-defined in Applications >> Schedule setup. The default
setting of this field is blank and the function will always
work.
WAN Connection
Detection
Such function allows you to verify whether network
connection is alive or not through PPP Detect or Ping Detect.
