Vigor2862 Series User’s Guide
121
WAN links for Channel 5, 6 and 7 are provided for router-borne application such as TR-069.
The settings must be applied and obtained from your ISP. For your special request, please
contact with your ISP and then click WAN link of Channel 5, 6 or 7 to configure your router.
Available settings are explained as follows:
Item Description
Enable Channel 5/6/7
Check it to enable this channel.
WAN Type Specify a WAN type of the PVC Channel/VLAN.
ADSL- A PVC Channel will be created using an ADSL
connection on WAN1.
VDSL- A VLAN will be created using a VDSL connection on
WAN1.
Ethernet (WAN2) - A VLAN will be created on WAN2.
General Settings VPI - (Available when WAN Type is ADSL) Virtual Path
Identifier. Contact your ISP or carrier for the appropriate
value.
VCI - (Available when WAN Type is ADSL) Virtual Channel
Identifier. Contact your ISP or carrier for the appropriate
