Vigor2862 Series User’s Guide
14
Available settings are explained as follows:
Item Description
General Setup Allow to configure settings for each subnet respectively.
Index - Display all of the LAN items.
Status- Basically, LAN1 status is enabled in default.
LAN2 –LAN6 and IP Routed Subnet can be observed by
checking the box of Status.
DHCP/DHCPv6- LAN1 is configured with DHCP/DHCPv6 in
default. If required, please check the DHCP box for each
LAN.
IP Address - Display the IP address for each LAN item. Such
information is set in default and you can not modify it.
Details Page - Click it to access into the setting page. Each
LAN will have different LAN configuration page. Each LAN
must be configured in different subnet.
IPv6 – Click it to access into the settings page of IPv6.
DHCP Server Option DHCP packets can be processed by adding option number and
data information when such function is enabled.
To Next Page
