Vigor2862 Series User’s Guide
17
Available settings are explained as follows:
Item Description
Enable Check this box to enable such port redirection setting.
Mode Two options (Single and Range) are provided here for you to
choose. To set a range for the specific service, select Range.
In Range mode, if the public port (start port and end port)
and the starting IP of private IP had been entered, the
system will calculate and display the ending IP of private IP
automatically.
Service Name Enter the description of the specific network service.
Protocol Select the transport layer protocol (TCP or UDP).
WAN Interface Select the WAN interface used for port redirection. There
are eight WAN IP alias that can be selected and used for port
redirection. The default setting is All which means all the
incoming data from any port will be redirected to specified
range of IP address and port.
Public Port Specify which port can be redirected to the specified Private
IP and Port of the internal host. If you choose Range as the
port redirection mode, you will see two boxes on this field.
Type the required number on the first box (as the starting
port) and the second box (as the ending port).
Source IP Use the drop down list to specify an IP object. Or click IP
Object link to create a new one for applying.
Private IP Specify the private IP address of the internal host providing
the service. If you choose Range as the port redirection
mode, you will see two boxes on this field. Type a complete
IP address in the first box (as the starting point). The second
one will be assigned automatically later.
Private Port Specify the private port number of the service offered by the
internal host.
After finishing all the settings here, please click OK to save the configuration.
