Vigor2862 Series User’s Guide
259
Click Diagnose to get the following page.
or
Available settings are explained as follows:
Item Description
Mode Analyze a single packet – Choose such mode to make Vigor
router analyze how a single packet will be sent by a route
policy.
Analyze multiple packets… - Choose such mode to make
Vigor router analyze how multiple packets in a specified
file will be sent by a route policy.
Packet Information Specify the nature of the packets to be analyzed by Vigor
router.
Protocol - Specify a protocol for diagnosis.
Src IP – Type an IP address as the source IP.
Dst IP – Type an IP address as the destination IP.
