Vigor2862 Series User’s Guide
81
Item Description
Enable/Disable Click Enable for activating this function. If you click Disable,
this function will be closed and all the settings that you
adjusted in this page will be invalid.
ADSL Modem Settings It is not necessary to configure settings in these fields for
modem settings are prepared for ADSL only.
IP Network Settings Obtain an IP address automatically – Click this button to
obtain the IP address automatically.
More Options – Click it to display router name and
domain name items.
Router Name – Type in the router name provided
by ISP.
Domain Name – Type in the domain name that you
have assigned.
DHCP Client Identifier* - Check the box to specify username
and password as the DHCP client identifier for some ISP.
Username: Type a name as username. The
maximum length of the user name you can set is
63 characters.
Password: Type a password. The maximum length
of the password you can set is 62 characters.
Specify an IP address – Click this radio button to specify
some data.
IP Address – Type in the private IP address.
Subnet Mask – Type in the subnet mask.
Gateway IP Address – Type in gateway IP address.
WAN IP Alias - If you have multiple public IP addresses and
would like to utilize them on the WAN interface, please use
WAN IP Alias. You can set up to 32 public IP addresses other
than the current one you are using. Notice that this setting is
available for WAN1 only. Type the additional WAN IP address
and check the Enable box. Then click OK to exit the dialog.
