VigorAP 902 User’s Guide
93
Backup
Click it to store the settings (MAC addresses on MAC Address
Filter table) on this page as a file.
Restore
Click it to restore the settings (MAC addresses on MAC
Address Filter table) from an existed file.
After finishing this web page configuration, please click OK to save the settings.
3
3
.
.
8
8
.
.
4
4
W
W
P
P
S
S
Open Wireless LAN>>WPS to configure the corresponding settings.
Available settings are explained as follows:
Item Description
Enable WPS
Check this box to enable WPS setting.
WPS Configured
Display related system information for WPS. If the wireless
security (encryption) function of VigorAP 902 is properly
configured, you can see ‘Yes’ message here.
WPS SSID
Display current selected SSID.
WPS Auth Mode
Display current authentication mode of the VigorAP 902r.
Only WPA2/PSK and WPA/PSK support WPS.
WPS Encryp Type
Display encryption mode (None, WEP, TKIP, AES, etc.) of
VigorAP 902.
Configure via Push
Button
Click Start PBC to invoke Push-Button style WPS setup
procedure. VigorAP 902 will wait for WPS requests from
wireless clients about two minutes. Both ACT and 2.4G
WLAN LEDs on VigorAP 902 will blink quickly when WPS
is in progress. It will return to normal condition after two
minutes. (You need to setup WPS within two minutes)
Configure via Client
PinCode
Type the PIN code specified in wireless client you wish to
connect, and click Start PIN button. Both ACT and 2.4G
WLAN LEDs on VigorAP 902 will blink quickly when WPS
is in progress. It will return to normal condition after two
minutes. (You need to setup WPS within two minutes).
