VigorAP 902 User’s Guide
97
VigorAP 902.
Encryption
Display the encryption mode for the scanned AP.
Authentication
Display the authentication type that the scanned AP applied.
Mode
Display the wireless connection mode that the scanned AP
used.
Ch. Width
Display the channel width that the scanned AP used.
Scan
It is used to discover all the connected AP. The results will be
shown on the box above this button
Channel Statistics
It displays the statistics for the channels used by APs.
AP’s MAC Address
If you want the found AP applying the WDS settings, please
type in the AP’s MAC address.
AP’s SSID
To specify an AP to be applied with WDS settings, you can
specify MAC address or SSID for the AP. Here is the place
that you can type the SSID of the AP.
Add
Click Repeater for the specified AP. Next, click Add. Later,
the MAC address of the AP will be added and be shown on
WDS settings page.
3
3
.
.
8
8
.
.
7
7
W
W
D
D
S
S
A
A
P
P
S
S
t
t
a
a
t
t
u
u
s
s
VigorAP 902 can display the status such as MAC address, physical mode, power save and
bandwidth for the working AP connected with WDS. Click Refresh to get the newest
information.
