VigorSwitch P2280 User’s Guide
144
V
V
-
-
2
2
-
-
2
2
E
E
g
g
r
r
e
e
s
s
s
s
S
S
h
h
a
a
p
p
i
i
n
n
g
g
R
R
a
a
t
t
e
e
This page allows a user to configure egress port rate limit. The egress rate limit is the number
of bits per second that can be received from the egress interface. Excess bandwidth above
this limit is discarded.
Available settings are explained as follows:
Item Description
Egress Shapping Rate
Ports Use the drop down list to select the port profile (GE1 to GE28)
or profiles.
State Disable – Disable egress bandwidth control.
Enable - Enable egress bandwidth control.
CIR (Kbps) Enter the rate value,<16-1000000>,unit:16 Kbps.
Apply Apply the settings to the switch.
Modify
- Click it to modify the settings for the selected port
profile.
