Trunk - An untagged member of one VLAN at most, and is a
tagged member of zero or more VLANs.
PVID A PVID (Port VLAN ID) is a tag that adds to incoming untagged
frames received on a port so that the frames are forwarded to
the VLAN group that the tag defines.
For port under Access Mode, VLAN ID provided as PVID would
automatically be selected as the untagged VLAN.
Accepted Type Specify the acceptable-frame-type of the specified interfaces.
It’s only available with Hybrid mode.
All - Accept frames regardless it's tagged with 802.1q or not.
Tag Only - Accept frames only with 802.1q tagged.
Untag Only - Accept frames untagged.
Ingress Filtering Enable the ingress filtering to filter out any packets not belong
to any VLAN members of this port. It is enabled automatically
while operating in Access and Trunk mode.
Enabled – Click it to enable the function.
Disabled - Click it to disable the function.
Tagged VLAN Specify the VLAN profile tagged in the VLAN.
Untagged VLAN Specify the VLAN profile untagged in the VLAN.
Forbidden VLAN Specify the VLAN profile forbidden in the VLAN.
Apply Apply the settings to the switch.
Modify
- It is used to edit settings for the selected port.
