5.1 Application
The pump controller PC-200 is made to control up to 3 pumps. In the application menu you set how
many pumps the station has and how many of these pumps are allowed to run at the same time.
The unit can be configured to control the pumps with only level floats.
Advanced mode –
The advanced / not advanced mode is a mean to with just one simple settings change can convert an
advanced pump controller with many functions, to a simple controller with only basic pump control
functions.
Menu - Application
Here you set how many pumps
the station has.
Here you set how many pumps
are allowed to run at the same
time.
Here you set if the pumps are
used for filling or emptying of
pumpsump.
Here you set if you want the
unit for advanced (all functions)
mode or Basic (just the most
necessary functions) mode.
S y s t e m s e t t i n g s . ►
When you are in a menu where you want to
change a value you choose the parameter you
want to change and enter the changing mode by
pressing the OK key.
Now the cursor will flash in front of the value you
want to change. Use the ▲kay to see the
alternatives and accept wanted alternative with
the OK key.
Advanced mode –NO ( Basic mode )
In Basic mode you will access the following basic
functions:
- Start and stop functions for 1 to 3 pumps.
- Alternation of pumps
- Use of analogue level sensor or level switches
- Comunication and sending of SMS alarms
- One digital pulse counter for flow, energy or rain.
- Alarm handling with alarm history (up to 15 alarms).
Advanced mode –YES
In advanced mode you will access the following
additional functions:
- One additional analogue input (free choice) with
alarm set points
- Voltage relay
- Current measurement and/or running confirmation
- Inputs for the pumps termoswitches
- Mixer functions
- Attendance check
