5.2 I/O Settings
The unit has following in and outputs:
- 10 Digital inputs
- 7 Digital outputs
- 1 Digital pulse counter
- 2 Analogue inputs (4-20 mA)
- 3 Voltage inputs
- 3 Current inputs (5 A current transformers)
- 3 Temperature protection inputs (digital)
All these In and Outputs are predefined for what they are used for, but you have to select if they are to
be used or not, which shall generate alarms, signal delays, measuring ranges for analogue inputs etc.
For a complete overview of all In and Outputs refer to the table in chapter 10.
