5.4.5 Attendance check (Person alarm or Intruder alarm)
Personalarm/ Intruder alarm- to create a signal an analoge input is used which is changed to a
digital signal by connecting an resistor in series with the analogr signal
Person alarm
For the function person alarm the input is activated via a signal cable that is connected to the light
switch in the station and starts an internal timer which after a set time activates a relay output. This
output can for example be connected to a horn or flashing light to inform the operator that the
operator time is finished and has to be prolonged. If this is not done a person alarm will be sent . To
avoid that this happens the light switch has to be turned off and on.
Intruder alarm
The function intruder alarm is activated via a signal cable that is connected to for ex. a magnetic
sensor in the door and starts an internal timer which is set to after a certain set time activates a relay.
This relay output can be connected to a horn or flashing light and send an intruder alarm. To avoid that
the alarm is sent a password must be entered on the keyboard.
A t t e n d a n c c h e c k .►
◄
s i g n a l t y p e
◄◄ N C / N O
C o n t . s i g n a l
◄◄ N o
L o g i n t i m e [ s ]
◄◄ 0
L o g o u t t i m e
◄◄ 0
S i g n a l t y p e
◄◄ N C / N O
N e j
0 . 5 0 c y k l i s k
C o n t i n o u s h o r n
◄◄ N o
V i s i t t i m e [ s ]
◄◄ 1 8 0 0
T i m e t o a l a r m .
◄◄◄ 1 8 0
▼▲
▼▲
▼▲
▼▲
▼▲
▼▲
▼▲
▼▲
▼▲
Choice between person alarm, intruder alarm and none
Choice between NC and NO
Choice between Yes and No
Personalarm
Intruder alarm
A t t e n d a n c e c h e c k ►
◄
Choice between person alarm, intruder alarm or none
Choice between NC and NO
Choice between Yes and No
The time needed for work in the station
Time before alarm is sent
Time before alarm is sent
when opening the door
Time before alarm is sent,
when the password is keyed in and door not closed
