5.2.7 Temperature protection.
The unit has one input for term contacts in the motor winding, for each pump which if activated, will
stop the pump when the thermo contact is activated. When the term contacts function is used you have
the option to choose for the pump to stop and be able to start again once the term contact is
deactivated, or you can choose to block the pump which means that once the term contact is activated
and the pump stops, it will not be able to start again until the term contact alarm is manually
confirmed.
T e m p . p r o t e c t o r s ►
◄
P 1 T e m p . p r o t . ►
◄◄
P 2 T e m p . p r o t . ►
◄◄
F u n c t i o n
◄◄◄ i n u s e
S i g n a l t y p e
◄◄◄ N O
A l a r m f u n c t i o n
◄◄◄ Y e s
A l a r m d e l a y . [ s ]
◄◄◄ 1 . 0
Following choices, in use and
not in use
Following choies NO och NC
Here the delay is set in sec.
är ställs fördröjningen in
I sekunder
Following choices, Yes and No
Settings for P2 and P3 are
done as for P1
P 3 T e m p . p r o t . ►
◄◄
Following choices YES or NO
To Next Page
