5.4.3 AI 2 Setpoints, Analogue setpoints
For the Analogue input 2 which is a free choice/editable function adabtable to your specific needs
to measure analogue signals, pH, conductivity, flow etc.
For this signal you can set a high and a low set point which can be used to generate alarms for
example.
A I 2 S e t p o i n t s .►
◄
S e t p o i n t v a l u e
◄◄◄ 0 . 5 0
A l a r m f u n c t i o n
◄◄◄ N o
A l a r m d e l a y [ s ]
◄◄◄ 0 . 0
S e t p o i n t v a l u e
◄◄◄ 0 . 5 0
A l a r m f u n c t i o n
◄◄◄ N o
A l a r m d e l a y [ s ]
◄◄◄ 0 . 0
Here you set if the alarm
function shall be active or not
Here the setpoint for low alarm
is set
Here you set if the alarm
function shall be active or not
Here the time for alarm delay is
set
Here the setpoint for high
alarm is set
Here the time for alarm delay is
set
To Next Page
